Thrust:30kg
Diameter:132mm
Length:333mm
Weight:2560g
Speed range:38000～98000
Idle RPM:38000
Rated exhaust Max Temp:750℃
Fuel consumption:≤820g/min
Fuel used:Aviation kerosene
Lubricating oil: 3%～5%
Maintenance cycle: 25H
Power line
Throttle line
Signal line
GSU
Brushless Fuel Pump
ECU(V3)
Filter
Switch Valve
| Engine start | Engine operation | Starting motor | |||
| Pump Voltage | 0.5-1V | RPM ACC | 25 | Eject time | 0.4S |
| RPM Start Up Ramp | 100 | RPM DEC | 25 | Ejection Low Volt | 4V |
| Pump Start Up Ramp | 3 | Idle RPM range | 38000～98000 | Run Voltage | 5V |
| Valve | 40 | Max Temp | ≤1000 | Cooling | 4000 |
| Ignition RPM | 3000 | Low Volt | ≥10V | ||
| Preheat RPM | 4000 | Restart | Off | ||
| RPM Off Starter | 16000 | Restart Glow Plug | Consistent with the fire head Low Volt | ||
| Pump Limit | 13V | ||||
RPM:97,000
6 mm Oil in 4 mm Oil delivery
√ Using only one bus to transmit data signals,
√ More stable communication between the engine and the control system
√ The connection is more convenient and concise
32 Bit element high-Speed range chip
